SW-Motech Crash Bars for the Honda XL750 Transalp

The SW-MOTECH Crash Bars (SBL.01.070.10002/B) provide comprehensive lateral and engine impact protection for the Honda XL750 Transalp. When riding off-road or navigating rocky terrain, low-speed tip-overs and slide-outs place the Transalp's wide plastic fairings, side-mounted radiator cores, and exposed engine clutch and alternator covers at risk of severe structural damage.

Constructed from heavy-duty 27mm outer-diameter tubular steel with a durable 2.5mm wall thickness, these crash bars are CNC cold-bent and robotically welded to ensure dimensional accuracy. The system mounts directly to rigid frame anchor points on the motorcycle chassis, distributing lateral impact loads evenly across the frame rather than concentrating stress into the aluminum engine cases. A multi-stage surface treatment—consisting of an anti-corrosion primer followed by a durable black powder coat—protects the steel tubing from rust, stone chipping, and trail abrasion.

Features:

• Heavy-Wall Tubular Steel: Built from 27mm outer-diameter steel tubing to deliver high torsional strength and impact deflection during drops and slides.

• Radiator & Fairing Coverage: Extends outward and upward to create an impact buffer around delicate radiator tanks and expensive painted bodywork.

• Frame-Mounted Load Path: Anchors to strong chassis points, isolating the engine castings and cylinder head from direct collision forces.

• Corrosion-Resistant Finish: Dual-layer surface protection with an anti-rust base coat and textured black powder topcoat.

• Unrestricted Service Access: Form-fitted geometry maintains easy access to the oil dipstick, oil filler cap, and routine maintenance points without bar removal.

• Direct Bolt-On: Fastens directly to factory mounting locations with no drilling, cutting, or fairing modifications required.

What's in the Box:

• 1x Left-Side Crash Bar (Black Powder-Coated Steel)

• 1x Right-Side Crash Bar (Black Powder-Coated Steel)

• Bike-Specific Steel Mounting Brackets & Spacers

• Complete Mounting Hardware Kit

• Installation Instructions

Fitment:

• 2024–2026 – Honda XL750 Transalp

Fitment Notes:

• Accessory Compatibility: Fully compatible with the SW-MOTECH Engine Guard Skid Plate (MSS.01.070.10001/B) and OEM Honda skid plate options.

• Auxiliary Light Mounts: Accepts standard 27mm clamp-on light mounts for aftermarket LED driving or fog lights.

Part Number: SBL.01.070.10002/B
